Century 56J C-Face 2-1/2 HP Single Speed Up Rated Pool Filter Motor, UST1252

Sale!
Century 56J C-Face 2-1/2 HP Single Speed Up Rated Pool Filter Motor, UST1252

Century 56J C-Face 2-1/2 HP Single Speed Up Rated Pool Filter Motor, UST1252

Original price was: $40.97.Current price is: $22.74.

74 in stock

SKU: AQOPENING32641 Category:

Description

Century UST1252 Up-Rated Two-Compartment Pool Filter Motor; 2.5 HP, 3450 RPM, 208-230 V, 56J, Threaded Shaft

Features

  • Sealed switch design
  • Low service factor
  • Energy efficient “Conservationist” motor
  • 7/16-20 UNF-2A RH threaded shaft

Specifications

Ambient Temperature 50 deg C Bearing Type Sealed Ball Brand Regal Beloit Diameter 6-1/2 Inch Duty Cycle Continuous Efficiency Group High Enclosure Design Open Dripproof Finish Color Satin Black Flange Material Aluminum Frame 56J Frequency Rating 60 Hz Full Load Amps 12.6-11.4 A HP 2.5 Insulation Class B Item Two-Compartment Pool Filter Motor Motor Design Capacitor Start/Run Motor Shaft Rotation CCWPE Motor Thermal Protection Auto Mounting Type C-Face Number of Speeds 1-Speed Overall Length 13.06 Inch Phase 1-Phase RPM 3450 Service Factor 1.06 Shaft Design Threaded Shaft Diameter 5/8 Inch Shaft Length 2-9/16 Inch Shaft Material 303 Stainless Steel Standards Approvals UL 1081 Approved, UL Recognized (E46412), CSA Certified (LR43341) Sub Brand Century Thrust Horsepower 2.75 Type Up-Rated, UAK Voltage Rating 208-230 V

Resources

  • Technical Info
  • Brochure
  • Operational Manual
